Brand Name : Vinncom
Model Number : VN-PS-03427-ON2
Certification : ISO 9000 ROHS
Place of Origin : China
MOQ : 5 pcs
Price : negotiable
Payment Terms : L/C, D/A, D/P, T/T
Connector : N Female
Frequency Range : 340-2700MHz
Impedance : 50 Ohm
Insertion Loss : 3.3 dB
Power Rating : 1500W
Product Name : Splitter
RoHS Compliant : Yes
Size : 318 × 25 × 25mm
Temperature Range : -55 to +85°C
VSWR : 1.25:1
340-2700MHz 2 Way Power Splitter
Part Number | VN-PS-03427-ON2 |
Operating Frequency ( MHz ) | 340-2700 |
Impedance ( Ohm ) | 50 |
VSWR | ≤1.25 |
Split Loss (dB) | ≤3.3 |
IM3 (dBc @ 2×43dBm) | -161 |
Application | Indoor & Outdoor |
Degree of Protection | IP65 |
Operating Temperature ( ℃ ) | -40 ~ + 80 |
Interface | N Female |
Handling Power (Watt, max) | 500 |
Peak Power (Watt, max) | 1500 |
Dimension (mm)(L×W×H, excl connector) | 318 × 25 × 25 |
Net Weight (g) | 610 ± 20 |
Packing Dimensions (mm,L×W×H) | 420×80×40 |
Packing Carton Size (mm,L×W×H) | 434×435×195 |
ROHS Compliance | Yes |
![]() |
340/380-2700MHz 2 Way N Female Power Splitter Images |
